README.md
Forensic
Forensic is an image processing library which aims to detect copy-move forgeries in digital images. The implementation is mainly based on this paper: https://arxiv.org/pdf/1308.5661.pdf
Implementation details
- Convert the
RGB
image toYUV
color space. - Divide the
R
,G
,B
,Y
components into fixed-sized blocks. - Obtain each block
R
,G
,B
andY
components. - Calculate each block
R
,G
,B
andY
componentsDCT
(Discrete Cosine Transform) coefficients. - Extract features from the obtained
DCT
coefficients and save it into a matrix. The matrix rows will contain the blocks top-left coordinate position plus the DCT coefficient. The matrix will have(M − b + 1)(N − b + 1)x9
elements. - Sort the features in lexicographic order.
- Search for similar pairs of blocks. Because identical blocks are most probably neighbors, after ordering them in lexicographic order we need to apply a specific threshold to filter out the false positive detections. If the distance between two neighboring blocks is smaller than a predefined threshold the blocks are considered as a pair of candidate for the forgery.
- For each pair of candidate compute the cumulative number of shift vectors (how many times the same block is detected). If that number is greater than a predefined threshold the corresponding regions are considered forged.
Install
First install Go if you haven't installed already, set your GOPATH
, and make sure $GOPATH/bin
is on your PATH
.
$ export GOPATH="$HOME/go" $ export PATH="$PATH:$GOPATH/bin"
Next download the project and build the binary file.
$ go get -u -f github.com/esimov/forensic $ go install
In case you do not want to build the binary file yourself you can obtain the prebuilt one from the releases folder.
Usage
$ forensic -in input.jpg -out output.jpg
Supported commands:
$ forensic --help __ _ / _| ___ _ __ ___ _ __ ___(_) ___ | |_ / _ \| '__/ _ \ '_ \/ __| |/ __| | _| (_) | | | __/ | | \__ \ | (__ |_| \___/|_| \___|_| |_|___/_|\___| Image forgery detection library. Version: -blur int Blur radius (default 1) -bs int Block size (default 4) -dt float Distance threshold (default 0.4) -ft float Forgery threshold (default 210) -in string Source -ot int Offset threshold (default 72) -out string Destination
Results
Original Forged ResultNotice
The library sometimes produce false positive detection, depending on the image content. For this reason i advice to adjust the settings. Also sometimes the human judgement is required, but in the most cases the library do a pretty good job in detecting forged images. The more intensive the overlayed color is, the more certain is that the image is tampered.
License
Copyright © 2018 Endre Simo
This project is under the MIT License. See the LICENSE file for the full license text.
