在小程序中使用的 Canvas 2D API 绘制本地图片

小程序自 2.9.0 起,不再推荐使用其自己封装的 Canvas Context,而是更加推荐大家使用标准的 Canvas 2D API 来完成相关操作。因此,对于开发者来说,需要将过去的 Canvas API 调整为新的标准的 API 。

刚好我最近也实现了类似的功能,将这部分逻辑分享给大家。

<view>
  <view><button bindtap="chooseImage">选择图片</button></view>
  <view><canvas id="myCanvas"  type="2d" style="background-color:gray;width: 100%;margin-top: 100rpx;"></canvas></view>
</view>
Page({
   chooseImage(){
    // 创建一个 Query
    const query = wx.createSelectorQuery()
    // 选中 Canvas 对象
    query.select('#myCanvas')
      .fields({
        node: true,
        size: true // 提取 Node 信息
      })
      .exec((res) => {

        // 获取到 Canvas Node
        const canvas = res[0].node

        // 获取到 Context
        const ctx = canvas.getContext('2d')
        wx.chooseMedia({
          count: 1,
          success: function (res) {
            // 提取图片的基本信息
            wx.getImageInfo({
              src: res.tempFiles[0].tempFilePath,
              success: imgInfo => {
                // 使用 canvas.createImage 来创建一个图片
                const img = canvas.createImage()
                img.src = imgInfo.path
                img.onload = () => {
                  // 将图片画在画布上
                  ctx.drawImage(img, 0, 0, imgInfo.width, imgInfo.height)
                }
              }
            })
          }
        })
      })
   }
})

本条目发布于2022年7月29日。属于小程序分类,被贴了 Canvas小程序 标签。
